Manufacturer: WEIDMULLER

Type: Switch Ethernet

Model: IE-SW-VL05M-5TX

Art No.: 1504280000

Voltage: 24 V DC

Alarm contact: 1 relay output with a current capacity of 1 A at 24 V DC

Console port interface: RS-232

Function DIP switch: Turbo-Ring, Master, Coupler, Reserve

Industrial protocol support: PROFINET device

Number of ports: 5x RJ45

Operating Temperature: -10 … +60 °C

Degree of Protection: IP30

Dimensions: 105 x 135 x 53.6 mm

Housing main material: metal

Type of mounting: DIN rail, Panel (with optional mounting kit)
