Manufacture: Westermo
Type: Rs-232 To Rs-422/485 Converter
Model: MA-42
Art. No.: 3042-4001

Power supply: 115/230 V
Current: 24 mA/12 mA
Frequency: 48 … 62 Hz
Interface Converter: RS-232 … RS-422/485
Fuse: 100 mA
Interface 1: EIA RS-232-C/RS-423-A CCITT V.24/V.10 25-position D-sub female, DCE
Interface 2: EIA RS-422/RS-485/CCITT V.11 Data rate Up to 115,2 kbit/s
Temperature range: 5 … 50°C
Terminal connection: RS-232-C/V.24
Dimensions (WxHxD): 161 x 53 x 139 mm
