Manufacturer: WIELAND

Type: Safety Switching Device

Model: SNE 4004KV

Part No.: R1.188.0570.0

Applications: Expansion of a devices enabling current paths, contact expansion in safety equipment

Rated Voltage: 24 VDC

Rated Consumption: 1 W

Rated Current/Peak Current: 65 mA/1000 mA

Response Time: 20 ms

Tightening Torque: 0.5 – 0.6 Nm

Output Relay: 4 enabling Current paths, OFF-delayed (NO contact), 3 Signaling Current paths, OFF-delayed (NO contact)

Ambient Temperature: -25 … 55 °C

Protection Class Housing/Terminals: IP 40 / IP 20

Weight: 0.2 Kg
