Manufacturer: SKF
Type: Radial shaft seal
Model: CR 80X100X10 HMS5 RG

Type of outside diameter: Rubber metal reinforced
Lip material: Nitrile rubber (NBR)
Seal design: HMS5
Compliance with standard: ISO 6194, DIN 3760
Shaft diameter: 80 mm
Housing bore diameter: 100 mm
Seal width: 10 mm
Operating temperature: min.-40 °C
Operating temperature: max.100 °C
Operating temperature, short periods: max.120 °C
Circumferential speed: max. 9.74 m/s
Rotational speed: max. 2 340 r/min
Pressure differential: 0.05 N/mm²
