Manufacturer: Pepperl + Fuchs

Type: Retro-Reflective Sensor

Model: OCS2000-M1K-N2

Part No: 106529

Effective Detection Range: 0 … 2 m

Operating Voltage: 6 … 20 V DC

Switching Voltage: 8 V DC (R_i Approx. 1 kΩ)

Switching Current: ≤ 100 mA

No-Load Supply Current I₀: ≤ 45 mA

Voltage Drop U_d: ≤ 2.5 V

Signal Output: 1 NAMUR Output NC/NO Programmable

Switching Type: Light on / Dark on

Switching Frequency f: ≤ 100 Hz

Light Source: LED 660 nm

Protection Degree: IP67

Ambient Temperature: -25 … 70 °C

Material: Housing: PBT, Optical Face: Scratch Resistant Mineral Glass Lens

Connection: Terminal

Dimensions: 30 x 30 x 102 mm

Weight: 0.13 kg
