Sick
SICK IM12-02BPO-ZW1 INDUCTIVE PROXIMITY SENSOR
32,50$
Availability: 4 in stock
Only 4 items left. *Delivery time: 3-5 business days. *Express delivery: Worldwide delivery by FedEX/DHL express courierManufacturer: SICK
Type: INDUCTIVE PROXIMITY SENSOR
Model: IM12-02BP0-ZW1
Part No.: 6011965
Applications: for use in the industrial environments
Sensing Range: 2 mm
Time delay before availability: 100 ms
Operating Voltage: 10 … 30 V DC
Ripple: 10 %
Switching frequency: 2000 Hz
Continuous current: 200 mA DC
Switching output: PNP
Switching mode: Normally closed
Connector type: PVC, 2 m
Enclosure rating: IP67
Ambient Operating temperature: -25 … 70°C
Diameter, housing length: 12, 50 mm
Housing: Threaded type
Housing material: Nickel-plated Brass
Sensing face material: Plastic
Mounting: flush mountable
| Manufacturer | Sick |
|---|---|
| Type of Product | Inductive Proximity Sensor |
| Model | IM12-02BP0-ZW1 |
| Part No. | 6011965 |
| Min. Sensing Range [mm] | 0 |
| Max. Sensing Range [mm] | 2 |
| Response Time [ms] | 100 |
| Min. Voltage [DC] | 10 |
| Max. Voltage [DC] | 30 |
| Nominal Voltage [DC] | 24 |
| Switch Output | PNP |
| Output Function | Normally Close |
| Connection | Cable |
| Cable Length [mm] | 2000 |
| Diameter [mm] | 12 |
| Length [mm] | 50 |
| Material | Plastic |
| Condition | New |
