Manufacturer: C-MAC
Type: Current Relay
Model: RC20
Part No: 913752

Supply Voltage: 220 V AC
Measurement Range: 1 … 20 mA
Frequency: 50 … 60 Hz
Power Consumption: 2.5 VA
Contact Configuration: 2 Changeover (CO)
Contact Voltage: 250 V AC
Contact Current: 8 A
No. of Poles: 1 Pole
Housing: NORYL-SE-1, Grey, Self-Extinguishing
Terminals: Nickel-plated brass
Operating Temperature: -20 … 60 °C
Dimensions: 76 X 38 X 74 mm
