Manufacturer: Emerson

Type: AC Servo Motors

Model: 190 U3F305JAAEA215320-SREL

Frame Size: 190

Stall Current [A]: 39.4

Rated Power [kW]: 11.1

Still Torque [Nm]: 63

Rated Torque [Nm]: 35.2

Rated Speed [rpm]: 3000

Max. Speed [rpm]: 4800

Constant Voltage [Vrms/krpm]: 98

Constant Torque [Nm/Arms]: 1.6

Drive VPWM Voltage [VAC]: 380/480

Number of Poles: 8

Brake Voltage [VDC]: 24

Brake Current [A]: 1.1

Brake Torque [Nm]: 67

Insulation Class: F

Weight [kg]: 44.5
