Manufacturer: ENDRESS+HAUSER
Type: Point Level Switch
Model: LIQUIPHANT T AC FTL2600010
Part No.: 9422020010
Description: Vibration Limit Switch for Liquid Level Detection in Storage Tanks, Tanks with Agitators, and Piping
Rated Voltage: 19 … 253 V AC
Rated Current Consumption Max.: 350 mA
Frequency: 50 … 60 Hz
Process Pressure: 40 bar
Process Temperature: -40 … 150 °C
Material: Stainless Steel
Protection Class: IP65 / IP67
Sensor Length: 128 mm
Ambient Temperature: -40 … 70 °C
