Manufacturer: Schaeffler INA
Type: Axial Angular Contact Ball Bearing
Model: ZKLN 3062 2RS
Replaces: ZKLN3062-2RS-XL, ZKLN3062-2RS
Dimensions
Bore Diameter d: 30 mm
Outer diameter D: 62 mm
Width B: 28 mm
Contact angle α: 60 °
Basic load ratings:
Dynamic Cr: 29000 N
Static C0r: 64000 N
Fatigue load limit, axial: 2900 N
Limiting speed for grease lubrication: 5000 rpm
Thermally safe operating speed: 2200 rpm
Sealing: 2RS, Contact lip seal on both side
Operating Temperature: -30 … +120 °C
