Manufacturer: HI-ROTOR KURODA
Type: Rotary Actuator
Model: PRN50SE-180-40

Vane: Single vane
Air condition: Filtered (5µ) lubricated or non-lubricated
Oscillating angle: 180°
Oscillating reference point: 40
Port size: G1/8
Minimum operating pressure: 1,0 bar
Operating pressure: 2 to 10 bar
Operating temperature: 5 to 60°C
Allowable radial load: 588 N
Allowable thrust load: 44,1 N
Allowable energy: 49,0 Mj
