Manufacturer: Merlin Gerin/ Schneider
Type: Adaptable Residual Current Device
Model: VIGIC6026581BA
Art No: 26581 BA
Range: Multi9
Rated Operational Voltage: 220 … 415 V AC
Frequency: 50 … 60 Hz
No. of Poles: 2
Rated Current: 25 A
Rated Insulation Voltage: 500 V AC
Rated Impulse Withstand Voltage: 6 kV
Earth-Leakage Sensitivity: 30 mA
Earth-Leakage Protection Class: Type AC
Tightening Torque: 2 Nm
Operating Temperature: -5 … 60 °C
Dimension: 87 X 63 X 74 mm
8826581B
