NTN 1308 Self-Aligning Ball Bearing
The NTN 1308 Self-Aligning Ball Bearing is engineered to accommodate misalignment and shaft deflection while maintaining excellent performance under both radial and light axial loads. With high speed capabilities and robust construction, it is ideal for demanding industrial applications.
Manufacturer: NTN
Type: Self-Aligning Ball Bearing
Model: 1308
Technical Information:
- Bore Diameter (d): 40 mm
- Outer Diameter (D): 90 mm
- Width: 23 mm
- Dynamic Load Rating: 29 kN
- Static Load Rating: 9.7 kN
- Fatigue Load Limit: 0.44 kN
- Limiting Speed: 10,000 tr/min
- Reference Speed: 7,400 tr/min
