Manufacturer: PEPPERL+FUCHS

Type: Electrode Relay

Model: HR-1011

Nominal Voltage: 230 VAC , 24 VAC or 115 VAC

Frequency: 48 … 62 Hz

Power Consumption: 1.5 VA

Response Sensitivity: 6 … 150 kΩ adjustable via potentiometer

Output: 2 changeovers, terminals 13, 14, 15 and 16, 17, 18

Contact Rating AC: 250 V / 4 A; DC: 110 V / 0.5 A

Protection Class Housing /Terminals: IP 40 / IP 20

Ambient Temperature: -20 … +60 °C

Dimensions: 60 X 109.7 X 70 mm

Weight: 0.25 Kg
