Manufacturer: PEPPERL+FUCHS
Type: Switch Amplifier
Model: WE77EX2
Part No.: 01543S
Supply Voltage: 230 V AC
Rated Switching Current: 1.2 … 2.1 mA
Power Consumption Max.: 0.7 W
Power Loss: 2.5 W
Output Contact: 1 Relay, 1 Changeover (CO)
Contact loading Ratings:
250 V AC / 4 A / 500 VA
Protection Type: Ex Explosion Protection
Protection Class: IP20
Ambient Temperature: -25 … 60 °C
Dimensions: 104 x 60 x 110 mm
