Pilz Pnoz X2.1 24VAC/DC 2N/O Safety Relay
Used
In stock15 unitsReady to ship
Pilz Safety Relay X2.1 24VAC/DC 2N/O with 2 Normally Open contacts, 5 A rated current, and 230 V AC15 contact voltage. Compact design with screw terminal connections and IP54 protection class.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Pilz Safety Relay X2.1 24VAC/DC 2N/O
Pilz Safety Relay X2.1 24VAC/DC 2N/O is designed for ensuring safety in industrial applications, providing reliable performance and protection for electrical circuits. This high-quality safety relay offers features such as a 24 V AC/DC supply voltage, a high contact current rating, and easy installation with screw terminal connections.
- Manufacturer: Pilz
- Type: Safety Relay
- Model: X2.1 24VAC/DC 2N/O
- ID. No.: 774306 446424
Technical Data:
- Rated Supply Voltage: 24 V AC / DC
- Rated Current Max.: 5 A
- Power: 2 W / 4.5 VA
- Frequency: 50 to 60 Hz
- Contact: 2 Normally Open (NO)
- Rated Contact Voltage:
- AC15: 230 V
- AC1: 240 V
- DC13 / DC1: 24 V
- Rated Contact Current:
- AC15 230 V: 5 A
- AC1 240 V / DC1 24 V: 6 A
- DC13 24 V: 4 A
- Type of Electrical Connection: Screw terminals
- Protection Class: IP54
- Ambient Temperature: -10 to 55 °C
- Dimensions: 87 x 22.5 x 121 mm
