Manufacturer: Siemens
Type: Miniature Circuit Breaker
Model: 5SY62027
MNR: 5SY62 C2

Brand Name: SENTRON
Tripping characteristic class: C2
Rated Voltage: 400 V AC
Frequency: 50/60 Hz
Rated operational current: 2 A
Insulation voltage Ui: 440 V AC
Switching capacity current Icu:
— at DC according to IEC 60947-2 rated value: 15 kA
— according to EN 60898 rated value: 6 kA
— according to IEC 60947-2 rated value: 30 kA
Short-Circuit Current Breaking Capacity (Icn): 5 kA
No. of Poles: 2
Power Loss: 1.2 W
Terminal tightening torque recommended: 2.5 … 3.5 Nm
Degree of protection: IP20, with connected conductors
Ambient operation temperature: -25 … 55°C
Standard: IEC/EN 60947-2 , IEC 60898, EN 60898
Dimensions: 90 x 36 x 76 mm
