Manufacture: Sace
Type: Circuit Breaker
Model: SR100

Supply Voltage Ue: 500 V
Rated Current Iu: 100 A
Operating Frequency: 50 … 60 Hz
No. of Poles: 3-Pole
Rated Breaking Capacity (Icn):
125 V DC: 15 kA
220 V AC: 20 kA
380 V AC: 12 kA
440 V AC: 9 kA
500 V AC: 7 kA
Standard: IEC 157-1, VDE C550, BS 4752
Contact rating: 220 V AC,4 A
