Manufacturer: Schneider Electric, Elau

Type: AC Servo Motors

Model: BSH0551T11A1A

Stall Torque [Nm]: 0.5

Stall Current [A]: 1.4

Max Current [A]: 5.4

Rated Voltage [V]: 480

Rated Power [kW]: 0.4

Rated Speed [rpm]: 8000

Max Speed [rpm]: 9000

Number of Poles: 6

Flange Size [mm]: 55

Shaft Diameter [mm]: 9

Shaft Length [mm]: 20

Key Width [mm]: 12

Protection Class [IP]: 50

Thermal Class: F

Weight [kg]: 1.075
