SICK STEGMANN DFS60BT8AK04096 INCREMENTAL ENCODER

The DFS60BT8AK04096 from Sick STEGMANN is a high-resolution incremental encoder designed for demanding industrial automation systems. With advanced TTL/RS422 electrical interface and robust mechanical design, it ensures precise feedback and consistent operation even in harsh conditions.

Manufacturer: Sick STEGMANN
Type: Incremental Encoder
Model: DFS60BT8AK04096
Part No.: 1035802 0717-0054

Technical Information

• Supply Voltage: 4.5 / 5.5 V
• Load Current: 30
• Connection Type: Cable, universal, 1.5 m
• Electrical Interface: TTL/RS422
• Shaft Diameter: 15 mm
• Maximum Operating Speed: 12,000 U/min-1
• Maximum Output Frequency: 600 kHz
• Mechanical Interface: Through hollow shaft, plastic
• Working Temperature: -20 / 100 °C
• Protection Class: IP 65
• Dimensions: 65 x 31 x 70 mm
