SNR Oval Flange Ball Bearing Unit EXFLZ.206
The SNR Oval Flange Ball Bearing Unit EXFLZ.206 is designed for efficient load handling and smooth operation in various industrial applications. With a high dynamic and static load rating, it ensures reliability and durability.
Manufacturer: SNR
Type: Oval Flange Ball Bearing Unit
Model: EXFLZ.206
Technical Information:
- Bore Diameter (d): 30 mm
- Housing Width / Diameter: 83 mm
- Housing Length, Width or Diameter: 142 mm
- Width of Inner Ring (B): 36.4 mm
- Distance Between Attachment Bolts (J): 116.5 mm
- Overall Unit Width: 48.3 mm
- Dynamic Load Rating: 19.5 kN
- Static Load Rating: 11.2 kN
