Manufacturer:  TELEMECANIQUE SCHNEIDER

Range: OsiSense XU

Series: GENERAL PURPOSE MULTIMODE

Type:  MULTIMODE PHOTOELECTRIC SENSOR

Model : XUX0AKSAT16

Detection System: Multimode

Sensing Range:

15 m polarised reflex need reflector XUZC50

3 m diffuse

60 m through beam need a Transmitter XUX0AKSAT16T

1.3 m diffuse with background suppression

Operating Voltage: 12 … 24 V DC

Switching Capacity: 100 mA

Switching Frequency: 250 Hz

Switching Output: Normally open/Normally closed

Adjustment: Teach in button

Connector Type: M16 Cable gland

Enclosure Rating: IP67

Ambient Operating Temperature: -25 … 55°C

Dimensions: 77 x 31 x 92 mm

Weight: 200 g

Housing Material: PBT

Lens Material: PMMA
