TIMMER A55K0600/000AAAA0000F0000AZV32 ISO CYLINDER

timmer-A55K0600_000AAAA0000F0000AZV32-iso-cylinder-(Used)
timmer-A55K0600_000AAAA0000F0000AZV32-iso-cylinder-(Used)-1
timmer-A55K0600_000AAAA0000F0000AZV32-iso-cylinder-(Used)
timmer-A55K0600_000AAAA0000F0000AZV32-iso-cylinder-(Used)-1

TIMMER A55K0600/000AAAA0000F0000AZV32 ISO CYLINDER

ISO Cylinder

The Timmer A55K0600/000AAAA0000F0000AZV32 ISO Cylinder features a 32 mm bore, 600 mm stroke, and double-acting operation. Built for industrial reliability with a square frame and G 1/8 pneumatic connection.

SKU: 1062704 Category: Tags: , , , , , , , , , , , , , , , , , , , , , , , , , , , ,
In stock: 1 pcs
Very low
Hurry! Only 1 left in stock.
Add to quote

Timmer A55K0600/000AAAA0000F0000AZV32 ISO Cylinder

The Timmer A55K0600000AAAA0000F0000AZV32 ISO Cylinder is a robust pneumatic actuator designed for reliable performance in industrial applications. It features a square shape, double operation mode, and high precision rod movement for demanding automation systems.

Manufacturer: TIMMER

Type: ISO Cylinder

Model: A55K0600/000AAAA0000F0000AZV32

Technical Information:

  • Media: Compressed Air
  • Bore Diameter: 32 mm
  • Stroke: 600 mm
  • Bore x Stroke: 32 x 600 mm
  • Rod Diameter: 10 mm
  • Frame Dimensions: 47 x 715 mm
  • Pneumatic Connection: G 1/8
  • Pressure Max.: 10 bar
  • Operation Mode: Double
  • Piston Rod End: Male
  • Shape: Square
  • Rod Direction: One Side
Weight1,96 kg
