Manufacturer: TURCK
Type: Isolating Switching Amplifier
Model: MS13-22Ex0-T
Supply Voltage: 20…250 VAC/20…125 VDC
Line Frequency: 40…70 Hz
Power Consumption: 3 W
Input Circuit Voltage: 8 V
Output circuits: 2 potential-free transistor outputs
Solid State Output: 30 V DC
Max. Output Switching Current: ≤ 50 mA per channel
Connection: 2 x 8 self-lifting pressure plates
Operating temperature: –25…+60 °C
