SIEMENS 3RV29 02-1DV0 SHUNT RELEASE

The Siemens 3RV29 02-1DV0 Shunt Release is designed for reliable tripping of circuit breakers in industrial electrical systems. Built according to IEC/EN 60947-2 standards, it offers robust performance, high insulation ratings, and dependable operation across a wide temperature range.

Manufacturer: Siemens
Type: Shunt Release
Model: 3RV29 02-1DV0
Standard: IEC/EN 60947-2

Technical Information

• Voltage: 350 / 415 V AC/DC, 50/60 Hz
• Insulation Voltage Rated Value: 690 V
• Rated Impulse Withstand Voltage (Uimp): 6 kV
• Connection: Screw Connection
• Operating Temperature: -20 / +60 °C
• Degree of Protection: IP20
• Dimensions: 18.5 x 90 x 68 mm
