Hiwin QHH15CA Linear Guideway Block
HIWIN QHH15CA LINEAR GUIDEWAY BLOCK
The Hiwin QHH15CA is a high-performance linear guideway block designed for demanding motion systems. With a square heavy-load block profile and top-mounting configuration, it provides excellent rigidity and precise linear movement in compact machinery setups.
Manufacturer: Hiwin
Type: Linear Guideway Block
Model: QHH15CA
MRN: QHH15CA 20008M-10E00
| Size | 15 mm |
| Total Height H | 28 mm |
| Block Width W | 34 mm |
| Block Length L | 61.4 mm |
| Block Height | 24 mm |
| Distances Between Holes | 26, 26 mm |
| Basic Load Rating, Dynamic Cr | 17.94 kN |
| Basic Load Rating, Static C‚r | 19.86 kN |
| Block Type | H; Square Type |
| Load Type | C; Heavy Load |
| Block Mounting Type | A; Mounting from Top |
