Advantech TPC-66SN Touch Panel Computer
Manufacturer: Advantech
Type: Touch Panel Computer
Model: TPC66SN
Part No.: TPC-66T
Input voltage: 18 … 32 V DC
Power Consumption: 12 W
Current: 3.15 A max.
Watchdog Timer: Programmable as 250 ms, 500 ms, 1 second
Enclosure: ABS
Mounting: Panel
LCD Display:
TPC-66SN:
Display Type: QVGA CSTN LCD
Display Size: 5.7″
Max. Resolution: 320 x 240
Max. Colors: 64 K
Luminance (cd/m2): 400
Viewing Angle (H/V): 100/55
TPC-66T:
Display Type: QVGA TFT LCD
Display Size: 5.7″
Max. Resolution: 320 x 240
Max. Colors: 64 K
Luminance (cd/m2): 300
Viewing Angle (H/V: 140/120
Touchscreen:
Type: 4-wire, analog resistive
Resolution: 1024 x 1024
Light Transmission: Above 75%
Lifespan: 10 million times with a silicone rubber of 8 mm
diameter finger
Ingress Protection: Front panel: NEMA4, IP65
Operating Temperature: 0 … 50°C
Dimensions (W x H x D): 195 x 148 x 44.4 mm
