ASCON XE-310/9 Multi-Input Controller
The ASCON XE3109 Multi-Input Controller is a versatile and high-performance process controller designed for precise temperature and process regulation. Featuring universal input compatibility, relay outputs, and time-proportioning control, it delivers dependable operation in industrial automation environments.
Manufacturer: ASCON
Type: Multi-Input Controller with Time-Proportioning
Model: XE-310/9
Configuration Code: 9999-9
Series: XE
| Input | Universal Configurable (RTD Pt100, Thermocouples J/L/K/S/R, 4“20 mA, 0“1 VDC, 0“10 VDC), Configurable Scale Range |
| Supply Voltage | 100 ... 240 V AC |
| Serial Communications | 20 mA |
| Main Output Y1 | Relay with Dual Action, 2 Contacts NO, 3A/250VAC |
| Logic Output | 0.15 VDC, 20 mA max. (for Static Relays) |
| Auxiliary Outputs Y2 - Y3 | Relay, 2 Contacts NO, 3A/250VAC |
| Number of Digits | 4 |
| Material | Self-Extinguishing UL94V1 |
| Protection Class | IP20 |
| Temperature | 0 / 50 °C |
| Dimensions | 96 x 48 x 120 mm |
