Schmalz VS-V-D-PNP / 10.06.02.00049 Vacuum Switch
新着
在庫あり1 ユニット即納可能
150,00$
真空スイッチ デジタル SCHMALZ VS-V-D-PNP 真空スイッチ、PNP出力、デジタル表示、および産業用空気圧アプリケーション向けの広いDC供給範囲。
中古
在庫あり 88,50$
この製品は中古でもご利用いただけます
中古バージョンを見る →
大量在庫
グローバル配送
専門的なサポート
品質保証
SCHMALZ VS-V-D-PNP Vacuum Switch
The SCHMALZ VS-V-D-PNP is a digital vacuum switch designed for precise monitoring of vacuum levels in pneumatic and automation systems. It features a clear digital display, robust overpressure resistance, and reliable PNP switching output for industrial applications.
Manufacturer: SCHMALZ
Type: Vacuum Switch
Model: VS-V-D-PNP
Art No.: 10.06.02.00049
| Measured Media | Non-aggressive gases; dry, oil-free air |
| Pressure Measuring Range | -1 / 0 bar |
| Display | Digital display |
| Max. Overpressure Resistance | 5 bar |
| Overpressure Resistance | 2 digital |
| Switching Capacity [mA] | 180 mA |
| Inputs / Outputs | 2 × LED |
| Switching Capacity (Max) | Male connector M8, 4 pole |
| Indication / Supply Voltage | 10.8 “ 30 V DC |
| Operating Temperature | 0 / 50 °C |
