B&R 3DI450.60-9 DIGITAL INPUT MODULE

B&R Automation Digital Input Module 3DI450.609

B&R Automation Digital Input Module 3DI450.609 is designed to provide reliable and efficient input functionality for industrial applications. Below are the key technical specifications:

• Manufacturer: B&R Automation
• Type: Digital Input Module
• Model: 3DI450.609
• MNR: DI 450
• Versions Rev.: C0

Technical Data:

• No. of Digital Input DI: 16
• No. of Inputs Counter Group: 4
• Input Voltage: 24 V DC
• Input Current at 24 V DC: Approx. 8 mA
• Frequency: 100 kHz
• Input Delay Typical: 1 ms (for input 1-8), 10 ms (for inputs 9 -16)
• Power Consumption Total: Max. 2 W
• Dimensions: 170 x 120 x 40 mm
