Controlli MVB46 Valve Actuator
Valve Actuator
Controlli MVB46 motoric valve actuator with 24 V AC supply, 450 N force output, 21 mm stroke, and floating control signal. Designed for reliable HVAC and industrial valve control with manual override and IP50 protection.Controlli MVB46 Valve Actuator
The Controlli MVB46 is a high-performance motoric valve actuator engineered for precise control, reliable positioning, and smooth operation in HVAC, industrial, and building automation systems. Designed for durability and efficiency, it delivers consistent force output and dependable operation even in demanding environments.
Manufacturer: Controlli
Type: Valve actuator
Model: MVB46
This actuator provides stable and accurate movement, making it ideal for regulating heating, cooling, and fluid control applications. The floating control signal ensures smooth modulation, while the manual override function allows safe operation during power loss or system maintenance. With its strong 450 N force output and IP50 protection, the Controlli MVB46 is built for long service life and dependable field performance.
| Supply Voltage | 24 V AC |
| Frequency | 50/60 Hz |
| Power Consumption | 5 VA |
| Force Output | 450 N |
| Operating Time | 65 s |
| Manual Drive | Pull and turn (Manual override) |
| Operating Modes | AUT / MAN |
| Stroke | 21 mm |
| Control Signal | Floating |
| Application | For valves |
| Actuators Type | Motoric |
| T Fluid max [°C] | 120 |
| Protection Degree | IP50 |
