Dold BN 5983.53/110 Emergency Stop Module

Name: DOLD BN 5983.53/110 EMERGENCY STOP MODULE
SKU: 967590
Availability: LimitedAvailability

dold-bn-5983-53_110-emergency-stop-module-1

dold-bn-5983-53_110-emergency-stop-module-2

dold-bn-5983-53_110-emergency-stop-module-3

dold-bn-5983-53_110-emergency-stop-module-4

dold-bn-5983-53_110-emergency-stop-module-5

中古

在庫あり4 単位即納可能

SKU

967590

カテゴリ

Safety Relays

コンディション

中古

Emergency Gates Module monitoring Of Relay Safety Stop

大量在庫

グローバル配送

専門的なサポート

品質保証

Manufacturer: DOLD

Type: EMERGENCY STOP MODULE

Model: BN 5983.53/110

Application: Emergency-stop circuits on machines / Monitoring of safety gates

Input:

Nominal Voltage: 24 VDC

Nominal Consumption: 5 VA ± 30 %

Control Current: max. DC 100 Ma

Output:

Output Contacts: 3 NO, 1 NC

Nominal Output Voltage: 400 VAC / 230 VDC

Contact Type: Relay, positively-driven

Wire Fixing: Flat terminals with self-lifting

Temperature Range: – 15 … + 55°C

Degree of Protection Housing / Terminals: IP 40 / IP 20

Dimensions: 100 X 74 X 121 mm

Weight: 0.84 Kg
