KBS BG,PTF-SUB2-VAR10NT150VA Interface Units/Controller
中古
在庫あり2 単位即納可能
666,66$
Interface Unit / Controller
The KBS PTF-SUB-2 controller connects and powers up to 100 light modules. Operating with 230 V AC supply and 24 VDC output, it features RS232C, RS485, or Ethernet communication for seamless industrial integration.AutomationBGControllerEthernetIndustrialInterfaceKBSLightModulePowerPTF-SUB-2PTF-SUB2-VAR10NT150VARS232CRS485supplySystemUnit
大量在庫
グローバル配送
専門的なサポート
品質保証
KBS PTF-SUB-2 Interface Unit / Controller
The KBS PTF-SUB-2 Interface Unit (Model BG,PTF-SUB2-VAR10NT150VA) is a high-performance controller designed as the standard device for systems with more than 50 light modules. It efficiently connects light modules to control computers, supporting up to four PTF bus segments and providing power for 50 to 100 light modules. Built with versatile communication options, this unit ensures reliable integration for industrial and automation systems.
Manufacturer: KBS
Series: PTF-SUB-2
Type: Interface Unit / Controller
Model: BG,PTF-SUB2-VAR10NT150VA
| Applications | Connection of Light Modules to the Control Computer |
| Capacity | Supports 50 to 100 Light Modules |
| Bus Connection | 4 PTF Bus Segments via 4 Output Terminals |
| Peripheral Connection | Two Serial Devices (e.g. Barcode Readers) |
| Voltage | 24 VDC |
| Power Supply | 230 V AC |
| Fuse Rating | 3.15 AT |
| Communication Interface | RS232C, RS485, or Ethernet |
| Dimensions | 280 × 280 × 90 mm |
| Design Features | Compact Housing, Reliable Signal Management, Easy Integration |
