Krohne IFC 080 K Altometer
新着
在庫あり2 単位即納可能
1 399,99$
高度計信号コンバーター KROHNE IFC080K 高度計信号コンバーター、DN 150、16 BAR、24 V AC " 16 VA、IFS 4000プライマリーヘッド用の較正付き。IP67保護の電気伝導性流体に適しています。
16AltometerbarcalibrationConductiveConverConverterDN150ElectricallyflowFluidIFC080KIFS4000IndustrialIP67KrohneSignal
大量在庫
グローバル配送
専門的なサポート
品質保証
KROHNE IFC080K ALTOMETER SIGNAL CONVERTER
The KROHNE IFC080K is a precision altometer signal converter designed for use with the IFS 4000 primary head. Built for accurate measurement of electrically conductive fluids, it supports reliable operation across a wide range of industrial applications with robust performance and IP67 protection.
Manufacturer: Krohne
Type: Altometer Signal Converter
Model: IFC080K
MRN: A94 7328
Pressure: 16 BAR
| Power | 24 V AC “ 16 VA |
| Magnetic Field Frequency | 1:6 |
| Current Strom | 0 / 20 mA |
| Pulses | 1 imp/m³ |
| Resistor | 0.7 KΩ |
| Calibration For | KROHNE IFS 4000 Primary Head |
| Nominal Diameter | DN 150 |
| Application Range | Electrically Conductive Fluids |
| Meter Size | DN 150 mm / 6 inch |
| Primary Construction | GK L5.288 |
| Range | 0 / 150 m³/h |
| Protection Class | IP 67 |
