Omron H3DE-S1 Solid-State Timer
新着
Manufacturer: OMRON
Type: Solid-State Timer
Model: H3DE-S1
Rated Supply Voltage: 24 … 230 VAC/DC
Frequency: 50/60 Hz
Power Reset: Minimum power-off time: 0.1 s
Reset Voltage: 2.4 VAC/DC max.
Time Setting: 0.1 s … 120 hrs
Power Consumption: AC: approx. 2.7 VA (1.6 W) at 230 VAC / DC: approx. 0.7 W at 24 VDC
Contact Output: 5 A at 250 VAC with resistive load / 5 A at 30 VDC with resistive load
Ambient Temperature: −10 … 55°C
Dimensions: 22.5 X 100 X 75.6 mm
Weight: 0.14 Kg
