SEW R47 DRS71S4BE05HR/MM03/EI7C HELICAL GEARMOTOR
The SEW R47 DRS71S4BE05HR/MM03/EI7C Helical Gearmotor offers high performance and durability for various industrial applications. This gearmotor features a robust helical gear unit with an output torque of 37 Nm and a total ratio of 14.56, providing reliable and efficient operation across a wide speed range.
Manufacturer: SEW
Type: Helical gearmotor
Model: R47 DRS71S4BE05HR/MM03/EI7C
Part No.: 01.1745625501.0001X11
Technical Specifications
- Gear unit: R47
- Input speed [r/min]: 1400 – 280
- Output speed [r/min]: 96 – 19
- Total ratio: 14.56 / infinite
- Output torque [Nm]: 37
- Service factor SEW-FB: 7.20
- Mounting position: M1
- Lubricant / Volume [l]: CLP 220 Miner.Oil / 0.70
- Output shaft end: 30x60mm lg.
- Motor power [kW]: 0.37 / 0.074
- Motor frequency [Hz]: 50
- Cyclic duration factor S1-S10: S1
- Motor voltage [V]: 380-500
- Motor supply frequency [Hz]: 50
- MM rated main current [A]: 1.30
- MM rated O/P current [A]: 1.60
- Brake voltage [V] / Torque [Nm]: 400 AC / 5
- Brake rectifier: BGM1
- Attached with: SEW MM03D-503-00 MOVIMOT INVERTER DRIVE
Input Specifications:
- Supply Voltage: 3-Phase 380 / 500 V AC
- Rated Current: 1.3 A
- Frequency: 50 / 60 Hz
Output Specifications:
- Rated Voltage: 3-Phase 0 / 380 “ 500 V AC
- Rated Current: 1.6 A
- Frequency: 2 / 120 Hz
