Siemens 1FT6062-1AF71-3EH1 Servo Motor
中古
在庫あり1 ユニット即納可能
SERVO MOTOR
Siemens 1FT6062-1AF71-3EH1 is a 270 V servo motor delivering 4.5 Nm rated torque and 3000 RPM speed, equipped with IP65 protection, F02 absolute encoder, and EBD 1.5B brake system for advanced automation use.1FT6062-1AF71-3EH1270V30004.5AbsoluteAutomationBrakeDriveEBDEncoderIndustrialIP65motorNmrpmServoSiemensTorque
大量在庫
グローバル配送
専門的なサポート
品質保証
SIEMENS 1FT6062-1AF71-3EH1 SERVO MOTOR
The Siemens 1FT6062-1AF71-3EH1 is a high-performance servo motor engineered for precise motion control in demanding automation environments. It delivers robust torque and speed characteristics with advanced encoder integration and a reliable braking system.
Manufacturer: SIEMENS
Type: SERVO MOTOR
Model: 1FT6062-1AF71-3EH1
Part No.: F420 1884 01
Technical Specifications
- Rated Voltage: 270 V
- Rated Speed: 3000 RPM
- Max Speed: 4800 RPM
- Stall Current: 3.4/4.0 A
- Rated Torque: 4.5 Nm
- Stall Torque: 6.0 Nm
- Protection Class: IP65
- Thermal Class: F
- Brake Voltage: 24 V
- Brake Power: 17 W
- Brake: EBD 1.5B
- Attached with: F02 2048 ABSOLUTE ENCODER
- S. No: KTY 84
