Siemens 3RV2011-0AA10 Circuit Breaker
中古
在庫あり1 ユニット即納可能
Circuit Breaker The SIEMENS 3RV2011-0AA10 SIRIUS is a 3-pole circuit breaker for motor protection, featuring a 0.16 A rated current, thermal overload release, and up to 690 V operation.
新着
在庫あり
この製品は新品でもご提供しております
新しいバージョンを表示 →
大量在庫
グローバル配送
専門的なサポート
品質保証
| SN | 1P3RV2011-0AA10+SG/230223 |
| Product Brand Name | SIRIUS |
| Design of the Product | For Motor Protection |
| Product Type Designation | 3RV2 |
| Operating Voltage Rated Value | 20 … 690 V |
| Operational Current Rated Value | 0.16 A |
| Insulation Voltage | 690 V |
| Operating Power | At AC-3/AC-3e, 400 V: 0.04 kW |
| Trip Class | 10 |
| Design Of The Overload Release | Thermal |
| No. Of Poles | 3 |
| Operational Short-Circuit Current Breaking Capacity (Ics) At AC | 400 V, 100 kA |
| Maximum Short-Circuit Current Breaking Capacity (Icu) At AC | 400 V, 100 kA |
| Frequency | 50/60 Hz |
| Tightening Torque | 0.8 to 1.2 Nm |
| Standard | IEC/EN/K 60947-2, IEC/EN/K 60947-4-1 |
| Type Of Electrical Connection | Screw-Type Terminals |
| Fastening Method | Screw and Snap-On Mounting Onto 35 mm DIN Rail |
| Protection Class | IP20 |
| Operating Temperature | -20 … 60°C |
| Dimensions | 97 x 45 x 97 mm |
| Stock Key | JO-004 |
| Condition | Used |
| SKU | 1103865 |
| Weight | 0,26 |
