Siemens 3SE5 112-0CH01 Position Switch
Position Switch
The **Siemens 3SE5112-0CH01 Position Switch** offers **1 NO, 1 NC contacts**, **IP66/IP67 protection**, **400 V insulation voltage**, and a **rotary actuator**, perfect for industrial position detection.Siemens 3SE5112-0CH01 Position Switch
The **Siemens 3SE5112-0CH01 Position Switch** from the **SIRIUS** series is designed for industrial position detection with reliable performance. Featuring a **rotary actuator** and **1 NO and 1 NC contacts**, this switch supports **400 V insulation voltage** and **6 kV surge voltage resistance**. Its **compact design** and **IP66/IP67 protection** make it suitable for tough environments. The switch offers **quick action contacts** and operates within the temperature range of **-25 to +85 °C**. Easy to install with **screw fixing** and **M20 x 1.5 cable entry**.
Manufacturer: Siemens
Type: Position Switch
Model: 3SE5112-0CH01
The **Siemens 3SE5112-0CH01 Position Switch** offers durable and precise position detection, making it ideal for various industrial applications.
| Insulation Voltage Rated Value | 400 V |
| Surge Voltage Resistance Rated Value | 6 kV |
| Actuator Type | Rotary right/left adjustable |
| Contact Operation | Quick action contacts |
| Thermal Current | 10 A |
| Contact | 1 NO, 1 NC |
| Operational Current at AC-15 at 230 V | 3 A |
| Protection Class | IP66/IP67 |
| Head Material | Plastic |
| Design of the Housing | Block, narrow |
| Material of the Enclosure | Metal |
| Cable Entry Type | 1x (M20 x 1.5) |
| Fastening Method | Screw fixing |
| Operation Temperature | -25 to +85 °C |
