Siemens 5SY4340-7CV Miniature Circuit Breaker
新着
在庫あり13 単位即納可能
Miniature Circuit Breaker SIEMENS SENTRON 3-pole miniature circuit breaker rated at 40 A with C tripping characteristic and 10 kA switching capacity, designed for industrial electrical circuit protection.
大量在庫
グローバル配送
専門的なサポート
品質保証
| Product Brand Name | SENTRON |
| Supply Voltage | 400V AC, 60V DC |
| Insulation Voltage | 440 V |
| Operational Current | 40 A |
| Switching Capacity Current | 10kA |
| No. of poles | 3 |
| Tripping Characteristic Class | C |
| Frequency | 50/60 Hz |
| Power Loss | 3,5 W |
| Number Of Modular Width Units | 3 |
| Fastening Method | DIN rail |
| Mounting Position | Any |
| Tightening Torque | 2.5 to 3.5 N·m |
| Ambient Temperature | -40 to 70 °C |
| Protection Degree | IP20 |
| Diameter | 70 mm |
| Dimensions | 90x54x76 mm |
| Condition | New |
| Stock key | JO-004 |
| SKU | 1093842 |
| Weight | 0,47 |
