Siemens 6ES7 131-6BH01-0BA0 Digital Input Module
中古
在庫あり1 ユニット即納可能
Digital Input Module SIEMENS digital input module with 16 digital inputs and 24 V DC rated operation, designed for industrial automation and control applications.
大量在庫
グローバル配送
専門的なサポート
品質保証
| Serial NO. | C-K9KD8332 |
| Product type designation | DI 16x24VDC ST |
| HW functional status | From FS02 |
| Firmware version | V0.0 |
| Rated value | 24 V DC |
| permissible range, lower limit | 19.2 V DC |
| permissible range, upper limit | 28.8 V DC |
| Current consumption | max. 90 mA |
| Power loss | 1,7W |
| Number of digital inputs | 16 |
| Sourcing/sinking input | P-reading |
| Width | 15 mm |
| Height | 73 mm |
| Depth | 58 mm |
| Ambient temperature | (horizontal installation, -30 to 60 °C), (vertical installation, -30 to 50 °C) |
| Condition | Used |
| Stock key | CON003 |
| SKU | 1093740 |
| Weight | 0,03 |
