Asahi Ucfa 209 Adjustable Flange Unit
Asahi UCFA 209 Adjustable Flange Unit
The Asahi UCFA 209 Adjustable Flange Unit is a versatile and durable solution for industrial applications. Featuring the FA 209 housing and UC 209 bearing, this unit ensures reliable performance and easy adjustability to suit a variety of systems requiring precision alignment and stability.
Manufacturer: Asahi
Type: ADJUSTABLE FLANGE UNIT
Model: UCFA 209
The Asahi UCFA 209 Adjustable Flange Unit is designed for systems requiring durable and flexible mounting, offering exceptional reliability and precision in demanding industrial environments.
| Bearing No. | UC 209 |
| Housing No. | FA 209 |
| Bore Diameter (d) | 45 mm |
| Overall Length (a) | 181 mm |
| Overall Height (b) | 108 mm |
| Width of Inner Ring (Bi) | 49.2 mm |
| Distance Between Attachment Bolts (e) | 148 mm |
| Overall Unit Width (z) | 52.2 mm |
| Diameter of Attachment Bolt Hole (s) | 16 mm |
| Locking Device | Set-Screw |
| Bolt Size | M14 |
