Balluff BTL032K Magnetostrictive Linear Position Sensor
신제품
요청 시 제공 가능
500,00$
250 mm 측정 범위, 0.2 µA 해상도, IP67 등급 및 견고한 알루미늄 하우징을 갖춘 정밀 선형 위치 센서.
2508-pinAutomationBalluffBTL032KConnectorControlIndustrialIP67LinearM16MagnetostrictivemmMotionPositionSensor
중고
재고 있음 350,00$
이 제품은 중고로도 구매하실 수 있습니다.
중고 버전 보기 →
방대한 재고
글로벌 배송
전문 지원
품질 보장
BALLUFF BTL032K MAGNETOSTRICTIVE LINEAR POSITION SENSOR
The Balluff BTL032K is a high-precision magnetostrictive linear position sensor engineered for industrial automation and motion control applications. With a durable aluminum housing and IP67 protection, it performs reliably even in harsh environments. Its compact design, high resolution, and robust connector system ensure consistent and accurate positioning feedback for a variety of systems.
Manufacturer: BALLUFF
Type: Magnetostrictive Linear Position Sensor
Model: BTL032K
Part No.: BTL5E10M0250PS32
ID No.: 084843132 HU
| Resolution | 0.2 µA |
| Rated Supply Voltage | 20 / 28 V DC |
| Rated Current Consumption Max. | 150 mA |
| Null Point | 73.0 mm |
| Magnets No. Max. | 1 |
| Measuring Range | 250 mm |
| Connection | Axial Connector, M16 x 0.75, 8-Pin |
| Housing Material | Aluminum |
| Protection Class | IP67 |
| Ambient Temperature | -40 / 85 °C |
