Dold BA9041 Phase Sequence Relay
Manufacturer: Dold
Type: Phase Sequence Relay
Model: BA9041
Part No: 0041732
Supply Voltage: 400 V AC
Frequency: 50 Hz
Contact Configuration: 2 Changeover (CO)
Contact Voltage: 230 V AC
Contact Current: 1 … 3 A
Thermal Current: 5 A
Fixing Torque: 0.8 Nm
Mounting: DIN rail
Housing: Thermoplastic
Operating Temperature: -20 … 60 °C
Degree of protection: Housing: IP 40, Terminals: IP 20
Dimensions: 45 X 3.2 X 119.8 mm
