Eltra EL40G1000S5/28P6X3PR Incremental Encoder
ELTRA EL40G1000S5/28P6X3PR INCREMENTAL ENCODER
The ELTRA EL40G1000S5/28P6X3PR is a compact and precise incremental rotary encoder engineered for industrial environments requiring accurate motion feedback. With a robust hollow shaft design and optical sensing, this encoder delivers reliable high-resolution performance.
Manufacturer: ELTRA
Type: Incremental Encoder
Model: EL40G1000S5/28P6X3PR
Serial No.: 08/3469/2
| Power Supply | 5 / 28 V DC |
| Principle of Operation | Incremental |
| Type of Sensor | Optical |
| Measurement Type | Rotary |
| Shaft Type | Hollow Shaft |
| Bore Diameter | 6 mm |
| Resolution | 1000 ppr |
| Construction Size (Diameter) | 42 mm |
| Max Rotation Speed | 3000 rpm |
| Max Output Frequency | 150 kHz |
| Enclosure Rating | IP54 |
| Output Type | Cable |
| Direction Type | Radial |
| Operating Temperature | -10 / +60°C |
