Motion Control Servo Motor Drives

Eurotherm ER-1220XRI DC Motor Controller

Name: EUROTHERM ER-1220XRI DC MOTOR CONTROLLER
SKU: 1083209
Price: 333.33 USD
Availability: InStock

eurotherm-er-1220xri-dc-motor-controller(new)

eurotherm-er-1220xri-dc-motor-controller(new)-1

eurotherm-er-1220xri-dc-motor-controller(new)-2

eurotherm-er-1220xri-dc-motor-controller(new)-3

eurotherm-er-1220xri-dc-motor-controller(new)-4

eurotherm-er-1220xri-dc-motor-controller(new)-5

신제품

재고 있음4 단위즉시 배송 가능

333,33$

DC Motor Controller

Schneider EUROTHERM ER-1220XRI controller with 1.8 kW output at 180 VDC, 110/240 V AC supply, 15 A current, isolated 4-quadrant terminals, and advanced alarm protection.

제조업체

EUROTHERM

SKU

1083209

카테고리

Servo Motor Drives

상태

신제품

1/8 4-Quadrant Armature Control Controller dc Drive ER-1220XRI Eurotherm Industrial kW motor Schneider System

방대한 재고

글로벌 배송

전문 지원

품질 보장

Schneider EUROTHERM ER-1220XRI DC Motor Controller

The Schneider EUROTHERM ER-1220XRI is a high-quality DC motor controller designed for armature applications. With advanced protection features and robust performance, it ensures reliable control for industrial operations.

Manufacturer: Schneider EUROTHERM

Type: DC Motor Controllers for Armature

Model: ER-1220XRI

Output Power	1.8 kW at 180 VDC / 0.9 kW at 90 VDC
Supply Voltage	110/240 V AC, single phase
Frequency	50“60 Hz
Current	15 A
Terminals	Fully isolated 4-Quadrant
Maximum Ratings (with max supply)	Armature: 12.2 A DC at 180 V / Field: 1.0 A DC, 215 V
Alarms	Stall Trip, 680 61220i fan monitoring
Operating Temperature	-10 / 50 °C
Dimensions	105 x 120 x 70 mm
