FAG 22309-E1 Spherical Roller Bearing
신제품
재고 있음22 단위즉시 배송 가능
제조사: Schaeffler FAG 종류: 구면 롤러 베어링 모델: 22309 E1 교체품: 22309-E1-XL, 22309E1
방대한 재고
글로벌 배송
전문 지원
품질 보장
Manufacturer: Schaeffler FAG
Type: Spherical Roller Bearing
Model: 22309 E1
Replaces: 22309-E1-XL, 22309E1
Dimensions:
Bore Diameter d: 45 mm
Outer diameter D: 100 mm
Width: 36 mm
Dynamic load rating: 187000 N
Static load rating: 183000 N
Fatigue load limit: 16500 N
limiting speed: 6800 RPM
Reference speed: 5000 RPM
Operating temperature: -30 … +200 °C
Design: E1, without central rip
