FAG N232-E-XL-M1-C3 Cylindrical Roller Bearing
신제품
요청 시 제공 가능
종류: 원통형 롤러 베어링
방대한 재고
글로벌 배송
전문 지원
품질 보장
Manufacturer: Schaeffler FAG
Type: Cylindrical roller bearing
Model: N232E-XL-M1C3
Dimensions:
Bore Diameter d: 160 mm
Outer diameter D: 290 mm
Width: 48 mm
Dynamic load rating: 590000 N
Static load rating: 670000 N
Fatigue load limit: 102000 N
Limiting speed for grease lubrication: 3600 rpm
Limiting speed for oil lubrication: 4200 rpm
Cage: Two Piece Brass Cage Roller Guided
Radial internal clearance: C3, Group 3
