Flender Himmel KF100-A100LP6 Helical Bevel Gear Units AND Geared Motor

Name: FLENDER HIMMEL KF100-A100LP6 HELICAL BEVEL GEAR UNITS AND GEARED MOTOR
SKU: 982924
Price: 2500.00 USD
Availability: InStock

flender-himmel-kf100-a100lp6-helical-bevel-gear-units-and-geared-motor-1

flender-himmel-kf100-a100lp6-helical-bevel-gear-units-and-geared-motor-2

flender-himmel-kf100-a100lp6-helical-bevel-gear-units-and-geared-motor-3

중고

재고 있음1 단위즉시 배송 가능

2 500,00$

제조업체

FLENDER

SKU

982924

카테고리

Gear Motors

상태

중고

3 AC Bevel E-motor Flender Gear Geared Helical Himmel motor Phase

방대한 재고

글로벌 배송

전문 지원

품질 보장

Manufacturer: Flender Himmel

Type: Bevel Gear Units and Geared Motor

Model: KF100-A100LP6

Sew KF100 Gear

Gear Type (KF): Helical Bevel Gear Unit, Flange-Mounted

Gear Box Size: 100

Ratio: 116.9

Shaft Diameter: 60 mm

Flange Diameter: 350 mm

Oil Quantity: 4.8 L

Sew DV100M6 AC Motor

Motor Size: 100L

No. of Pole: 6

Nominal Voltage (Delta): 220 V

Nominal Voltage (Star): 380 V

Rated Current (Delta): 7.3 A

Rated Current (Star): 4.2 A

Rated Power: 1.5 kW

Motor Speed: 935 r/min

Gear Unit Output Speed: 8 r/min

Power Factor: 0.72 %

Insulation Class: B

Frequency: 50 Hz

Degree of Protection: IP54

Gross Weight: 122.5 kg
