FOX F4/M3 Pressure Switch
재고 있음1 단위즉시 배송 가능
제조사: FOX 유형: 압력 스위치 시리즈: F4 모델: F4/M3
방대한 재고
글로벌 배송
전문 지원
품질 보장
Manufacturer: FOX
Type: Pressure Switch
Series: F4
Model: F4/M3
Switching pressure range: -0.8 Bar … 400 Bar
Maximum pressure: 25 Bar … 600 Bar
Body material: Zinc plated steel
Switching frequency: 90 cycles/min
Setting point: adjustable using internal screw
Switching accuracy: ± 4% of the end of scale at 20°C
Tightening torque max: 50 Nm
Connection: 1/4″
Supply Voltage: 250 VAC, 110 VDC
Working temperature: -25°C … +85°C
